F10-20 AC220V 380V 10A 10NO 10NC Auxiliary Switch For HV Distribution Electrical

Item No: F10-20

This series applies to the HV operating mechanisms switching on, switching off, interlock, and controlling of signal circuit. It also applies to HV switchgears, and can be used as transfer switch or cubicle switch.

Get A Quote

F10-20 AC220V 380V 10A 10NO 10NC Auxiliary Switch For HV Distribution Electrical

Electrical Products

Use Conditions
Structure
Advantages
Dimensions

Working Conditions of F10-20 Auxiliary Switch For HV Distribution

1. Ambient temperature: not higher than +40 °C, not less than -40°C

2. Altitude: not exceed 2000m.

3. Relative humidity: daily average of not more than 95%, month average of not more than 90%. Saturated vapor pressure daily average of not more than 2.2 × 103MPa, month average not more than 1.8 × 103MPa.

4.The acceleration is not greater than 15m/ square seconds;

5.The air is not significantly affected by dust, smoke, corrosive and flammable gas, steam or salt fog contamination.

Structure of F10-20 Auxiliary Switch For HV Distribution

1. According to different requirements, the turning angle of series F10 could be 60°~90°~120°.
2. Series F10 is divided into straight type and horizontal type according to the assembling method. It’s divided into horizontal structure and straight delay contact according to the way of construction.

Advantages of F10-20 Auxiliary Switch For HV Distribution

1. We are specialized in sales of high-voltage electrical insulation products: contact box, bending plate, insulator, sensor, wall bushing, contact arm bushing, insulated cylinder and tube.
2. Strict quality control and excellent after-sales service.
3. Experienced staffs answer all of your question in fluent English.
3. Customized design is available. OME&ODM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
