VSM-12 Series Handcart Type Permanent Magnetic Vacuum Circuit Breaker 12KV
-
VSM-12 Series Handcart Type Permanent Magnetic Vacuum Circuit Breaker 12KV
Summary:
VSM series of indoor high voltage vacuum circuit breaker is adopted front and rare construction for their permanent magnetic and vacuum interrupters. The main conducting circuit is with floor-standing type, the upper and lower outlet terminal and vacuum interrupters are Installed in one Insulation house. The insulation house is casted with epoxy resin material by APG technology, which can protect the surface of the vacuum Interrupters against dust accumulation and impact. It also has good Insulation property under humid, hot and pollution ambient condition. The vacuum circuit breaker with permanent mechanism is air-insulated, used for indoor Installation for different kind of power load, it is suitable for electrical net construction and reconstruction project in municipal net, rural net, mineral and railway net system, especially used in that fields which require frequently switching and have same requirement far short circuit operation cycles. This product was introduced by some International advance technique and processing technology with characteristics of intelligence, high reliability, long endurance and free maintenance etc.
Applying Ambient Conditions:
Ambient temperature: -25℃- +40℃
The height above sea level: ≤1000 m
Relative humidity: the average humidity of a day should be no more than 95%; the average humidity of a month should be no more than 90%.
Saturated vapor pressure: the average pressure of a day should be no mare than 2.2kPa; the average pressure of a month should be no more than1.8KPa.
Earthquake intensity: not exceed 8 degrees
It should be Installed in the places without fire, explosion, serious filth, and chemical erosion and violent vibration.
The product is accordance with standard of GB1984<HV AC. Vacuum circuit breaker> -
VSM-12 Series Handcart Type Permanent Magnetic Vacuum Circuit Breaker 12KV
-
VSM-12 Series Handcart Type Permanent Magnetic Vacuum Circuit Breaker 12KV
Ordering Instruction:
1. VCB full type, main technical specifications, phase distance and quantity
2. Type and specification of service voltage
3. The name and quantity of spare parts
